technoBOX application

Special standard enclosure made from ABS

Special standard enclosure made from ABS

Supporting rail with terminal block and additional accessories available

Integrated recess for e.g. front plates

Exterior hinges also available

External mounting made from ABS also available

Mounting plates and other accessories available




technoBOX

Modern and low cost enclosures for electronics and electrical devices

GOST

technoBOX is a modern and inexpensive range of plastic enclosures for all types of electronics and electrical equipment. It is molded in tough and long life ABS. The bevelled lid gives the housing an attractive appearance. A recess is provided in the lid for fitting a membrane keypad, front plate or product label. Threaded screw bosses in the lid and base can be used for fitting circuit boards, mounting plates, terminal rails etc. Mounting plates, front plates, cable glands and other accessories are also available.

We can supply technoBOX enclosures fully customized to your requirements.

Generate PDF






techno_box_variante_standard
  Type Part No. Length Width Height Weight (g) Mounting point D Mounting point E External mounting brackets Front plate self-adhesive Mounting plates Hinges Supporting rail for series terminals Feet Download 3D-Model-Download Add to my list
220.060.000 TBA 060 220.060.000 2.60 2.01 1.38 50 2.09 1.50 o - - - o o Download 3D-Model-Download Add to my list
220.080.000 TBA 080 220.080.000 3.27 3.19 2.36 170 2.76 1.97 o o o o o o Download 3D-Model-Download Add to my list
220.082.000 TBA 082 220.082.000 4.76 3.19 2.36 220 4.25 1.97 o o o o o o Download 3D-Model-Download Add to my list
220.084.000 TBA 084 220.084.000 6.34 3.19 2.36 220 5.83 1.97 o o o o o o Download 3D-Model-Download Add to my list
220.102.000 TBA 102 220.102.000 5.94 3.98 2.36 230 5.43 2.76 o o o o o o Download 3D-Model-Download Add to my list
220.104.000 TBA 104 220.104.000 7.91 3.98 2.36 300 7.40 2.76 o o o o o o Download 3D-Model-Download Add to my list
220.120.000 TBA 120 220.120.000 4.84 4.76 3.15 240 4.33 3.54 o o o o o o Download 3D-Model-Download Add to my list
220.122.000 TBA 122 220.122.000 7.91 4.76 3.15 400 7.40 3.54 o o o o o o Download 3D-Model-Download Add to my list
220.160.000 TBA 160 220.160.000 6.34 6.34 3.15 450 5.83 5.12 o o o o o o Download 3D-Model-Download Add to my list
220.162.000 TBA 162 220.162.000 9.49 6.34 3.15 650 8.98 5.12 o o o o o o Download 3D-Model-Download Add to my list
  Part No. Length Width Height Add to my list
220.060.000 220.060.000 2.60 2.01 1.38 Add to my list
220.080.000 220.080.000 3.27 3.19 2.36 Add to my list
220.082.000 220.082.000 4.76 3.19 2.36 Add to my list
220.084.000 220.084.000 6.34 3.19 2.36 Add to my list
220.102.000 220.102.000 5.94 3.98 2.36 Add to my list
220.104.000 220.104.000 7.91 3.98 2.36 Add to my list
220.120.000 220.120.000 4.84 4.76 3.15 Add to my list
220.122.000 220.122.000 7.91 4.76 3.15 Add to my list
220.160.000 220.160.000 6.34 6.34 3.15 Add to my list
220.162.000 220.162.000 9.49 6.34 3.15 Add to my list

⬤ standard   o available   - not available




Certifications

GOST

Enclosure sizes

10 sizes
Dimensions L x W x H
2,59" x 2,00" x 1,37" to 9,48" x 6,33" x 3,14"

Further information

Alternative Design due to slanted lid edges
Fastening points compatible with standard enclosures
Integrated recess in the lid for membrane keypad or front plates
Optional: External mounting brackets which can be turned by 90°
Full protective insulation in accordance with VDE 0100

Enclosure

ABS halogen-free, similar to RAL 7035 light gray
1° mold slope for casting ejection > internal circumference dimensions decrease by 1° towards enclosure bottom.
Special materials and colors on request

Flammability

UL 94 HB

Fastening

Separate screw channels outside of the enclosure interior.

Internal mounting

Fastening option for self-grooving screws on the base of the enclosure and in the lid

Ingress protection

IP 66 / EN 60529

Gasket

 Chloroprene O-ring gasket (CR), temperature resistance: -30°C to +90°C

Lid screws

Stainless steel 1.4567, captive
